| Manufacturer | Bticino |
| Reference | BTAL12DD |
| EAN | 8005543601662 |
| Customs code | 85365080 |
| Product line | Altège |
| Color | White |
| Surface finish | Matt |
| Material | Plastic |
| Nominal voltage | 230 V |
| Type of voltage | AC |
| Height | 73 mm |
| Width | 73 mm |
| Depth | 51 mm |
| Embedding depth | 33 mm |
| Angle de détection horizontal | 120 ° |
| Forced stop | Yes |
| Self-learning brightness function | No |
| Detection field of ground diameter | 8 m |
| Current of start max. | 1.8 A |
| Running time min. | 5 s |
| Frequency | 47 .. 63 Hz |
| Optimum mounting height | 1.2 m |
| Protection class (IP) | IP41 |
| Protection class against impacts (IK) | IK04 |
| Interconnectable | Yes |
| Max. span width | 6 m |
| Adjustable trigger brightness | Yes |
| Model type | Motion sensor |
| RAL number | 9003 |
| Max. detection range at H 2.5 | 8 m |
| Max. switching capacity | 250 W |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Temperature | 45 .. -5 °C |
| Surface treatment | Untreated |
| Type of sensor | Infrared |
| Type of connection | Screw terminal |
| Type of installation | Built-in |
| Type of connection | Screw terminal |
