| Manufacturer | Bticino |
| Reference | BTNT4055M2AN |
| EAN | 8005543586419 |
| Customs code | 85365080 |
| Product line | Living light |
| Color | Aluminum |
| Surface finish | Matt |
| Material | Plastic |
| Nominal voltage | 250 V |
| Unit height | 44 mm |
| Device width | 44 mm |
| Device depth | 36 mm |
| Min. depth of the flush-mounted box | 35 mm |
| With lighting | Yes |
| With indicator light indicator | Yes |
| Calibre | 10 A |
| Contact | 1 contact with closure |
| Protection class against impacts (IK) | IK02 |
| Model type | Push button unique |
| Number of actuating rockers | 1 |
| Nombre of contacts en tant que contacts to fermeture number of contacts as make contacts | 1 |
| Nombre of contacts en tant que contacts to ouverture number of contacts as NC contacts | 0 |
| Number of contacts as changeover switches | 0 |
| Number of modules (modular construction) | 2 |
| Number of poles | 1 |
| RAL number | 7035 |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Surface treatment | Lacquered / painted |
| Type of control | Push button |
| Type of connection | Automatic bollard |
| Type of mounting | Clip-on |
| Type of installation | Support of module |
| Type of connection | File terminal |
Reference: BTN4055M2AN
Pushbutton Livinglight contact NO 10A 250V~ to automatic terminals -white 2 modules
Reference: BTL4055M2AN
Pushbutton Livinglight contact NO 10A 250V~ to automatic terminals - anthracite - 2 modules
Reference: LN4380N
Lamp stand-alone plug-in Livinglight 230V - pressure lamp extraction 2MOD
Reference: BTN4053M2AN
Switch or two-way Livinglight 16ax 250V~ - white - 2 modules - set of 10u.
