| Manufacturer | Legrand |
| Reference | 005054 |
| EAN | 3245060050542 |
| Customs code | 85369010 |
| Product line | Plexo³ |
| Height | 30 mm |
| Width | 385 mm |
| Depth | 16 mm |
| Adapted to a massive conductor | Yes |
| Suitable for a multi-wire conductor | Yes |
| Intensity | 90 A |
| Number of poles | 55 |
| Number of 25 mm² connections | 5 |
| Number of heads | 45 |
| Number of entries | 10 |
| Total number of connections | 55 |
| Protected against contact | Yes |
| Conductor section, input | 35 .. 6 mm² |
| Conductor section, output | 1.5 .. 4 mm² |
| Type of installation | DIN rail |
| Type of connection | Without screws |
