| Manufacturer | Hager |
| Reference | BTC480E |
| EAN | 3250611500056 |
| Customs code | 85363030 |
| Nominal voltage | 240...415 V |
| Type of differential current | AC |
| With locking device | Yes |
| Degree of pollution | 3 |
| Frequency | 50Hz |
| Protection class (IP) | IP20 |
| Intensity | 125 A |
| Number of poles | 4 |
| Section of connection cable rigid | 10 .. 70 mm² |
| Ambient temperature in operation | -25 .. 60 °C |
| Rated impulse withstand voltage (Uimp) | 6 kV |
| Rated insulation voltage (Ui) | 500 V |
| Shock current resistance | 3 kA |
