| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | LED driver constant current |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Energy class | F |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 67.000-73.000 mA |
| Integrated diameter | 150 mm |
| Rated life L70/B50 at 25°C | 50000.000 h |
| Luminous efficacy of the lamp | 124 lm/W |
| Luminaire efficiency | 113 lm/W |
| Light distribution element | Reflector |
| Light emission | Direct |
| Recessed in insulated ceiling, fire protection "F with roof". | Yes |
| Glare assessment (UGR) | 22.000 |
| Power factor (cos phi) | 0.960 |
| Luminous flux (Lumen) | 1800 lm |
| Effective luminous flux | 3000 lm |
| Photobiological risk group according to EN 62471 | GR0 |
| Protection class (IP) | IP44 |
| Protection class against impacts (IK) | IK05 |
| Wall mounting | No |
| Number of lamps/modules | 1.000 |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 130.000 |
| Max. number of luminaires per circuit breaker C16 | 221.000 |
| Fire protection "D" | No |
| Accepted lamp power | 16 W |
| System power | 16.000 W |
| Reflector | Ultra glossy |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Wire surface | 2.500 mm² |
| Connectable conductor section | 1.5 mm² |
| Light source included | Yes |
| Light source included | Yes |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | -30 °C |
| Color temperature | 3000...4000 K |
| Glow-wire test according to IEC 60695-2-11 | 750 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Type of connection | File terminal |
| Color uniformity (mcAdam ellipse) | SDCM4 |
