| Manufacturer | Eaton |
| Reference | AFDD-20/2/B/003-A |
| EAN | 4015081822683 |
| Customs code | 85363030 |
| Type of differential current | A |
| Width in number of modules | 3 |
| Embedding depth | 67 mm |
| Calibre | 20 A |
| Overvoltage category | 3 |
| Energy limitation class (I²t) | 3 |
| Curve | B |
| Degree of pollution | 2 |
| Frequency | 50 Hz |
| Protection class (IP) | IP20 |
| Number of poles | 2 |
| Neutral pole simultaneously disconnected | No |
| Sensitivity | 0.03 A |
| Tension | 230 V |
| Type of control voltage auxiliary contact | AC |
