Reference: VAM100TDF1
Box lightning arrester type 12 2P Uc 300V Iimp 12,5kA with fuses 125A


You wish to have information on our products or to make a remark or a suggestion on our store? Do not hesitate to contact us .

Delivery times and stocks are indicated on each product sheet and are updated very regularly.
We do everything possible to provide you with quality products and we are listening to you so that you are fully satisfied with your purchases..
| Manufacturer | ADEE electronic |
| Reference | 174121 |
| EAN | 3382121741213 |
| Customs code | 85363030 |
| With remote signaling contact | No |
| Test class type 2 | Yes |
| Max. discharge shock current (8/20) | 40 kA |
| Nominal discharge current (8/20) | 20 kA |
| Protection class (IP) | IP20 |
| Interchangeable | Yes |
| Level of protection L-N | 1.5 kV |
| Level of protection N-PE | 1.5 kV |
| Number of wires (without grounding) | 2 |
| Short-circuit resistance (Isccr) | 100 kA |
| Max. flexible conductor cross-section (fine thread) | 35 mm² |
| Max. rigid conductor cross-section (single wire/multi wire) | 35 mm² |
| Signalling at the device | Optics |
| Type of installation | Top-hat rail 35mm |
| Up | 1.5 kV |
