| Manufacturer | Legrand |
| Reference | 406892 |
| EAN | 3245064068925 |
| Warranty | 2 years |
| Customs code | 85362010 |
| Product line | Dx³ |
| Color | Black |
| Surface finish | Glossy |
| Material | Metal |
| Type of voltage | AC |
| Suitable for flush mounting | Yes |
| Height | 82 mm |
| Width | 161 mm |
| Width in number of modules | 3 |
| Depth | 8.5 mm |
| Embedding depth | 44 mm |
| Calibre | 16 A |
| Energy limitation class (I²t) | 3 |
| Curve | C |
| Degree of pollution | 2 |
| Frequency | 50 .. 60 Hz |
| Protection class (IP) | IP20 |
| Protection class against impacts (IK) | IK04 |
| Recessed mounting | Yes |
| Number of modules horizontal (modular construction) | 4 |
| Number of modules vertical (modular construction) | 1 |
| Number of poles | 3 |
| Number of poles protected | 3 |
| Neutral pole simultaneously disconnected | No |
| Auxiliary products that can be combined | Yes |
| Material quality | Aluminum |
| Halogen-free | Yes |
| Section of connection cable rigid | 0.75 .. 16 mm² |
| Mounting direction | Horizontal and vertical |
| Ambient temperature in operation | -25 .. 70 °C |
| Tension | 400 V |
| Rated impulse withstand voltage (Uimp) | 4 kV |
| Rated insulation voltage (Ui) | 500 V |
| Surface treatment | Lacquered / painted |
| Type of mounting | Clip-on |
