| Manufacturer | Schneider Electric |
| Reference | A9F87210 |
| EAN | 3606480095924 |
| Customs code | 85362010 |
| Product line | Acti9 ic60 |
| Type of voltage | AC/DC |
| Suitable for flush mounting | No |
| Width in number of modules | 2.0 |
| Embedding depth | 44.5 mm |
| Calibre | 10.0 A |
| Curve | C |
| Frequency | 50,0 .. 60,0 Hz |
| Protection class (IP) | IP20 |
| Number of poles | 2.0 |
| Neutral pole simultaneously disconnected | No |
| Auxiliary products that can be combined | Yes |
| Section of connection cable rigid | 1,0 .. 25,0 mm² |
| Ambient temperature in operation | -35,0 .. 70,0 °C |
| Tension | 400.0 V |
| Rated impulse withstand voltage (Uimp) | 6.0 kV |
| Rated insulation voltage (Ui) | 500.0 V |
Reference: A9F76216
Acti9 iC60N - circuit breaker - 2P - 16A - curve B - 400Vca - 6000A/10kA
Reference: A9F84203
Acti9 iC60H - circuit breaker - 2P - 3A - curve C - 400Vca - 10000A/70kA
Reference: A9F77332
Acti9 iC60N - circuit breaker - 3P - 32A - curve C - 400Vca - 6000A/10kA
Reference: A9F87406
Acti9 iC60H - circuit breaker - 4P - 6A - curve C - 400Vca - 10000A/15kA
Reference: A9F75206
Acti9 iC60N - circuit breaker - 2P - 6A - curve D - 380/415Vca - 6000A/50kA
Reference: M9F22263
Multi9 C60SP - circuit breaker - 2P - curve C - 63A 5kA 480Y/277V - UL1077
Reference: M9F23208
Reference: A9F77420
Acti9 iC60N - circuit breaker - 4P - 20A - curve C - 400Vca - 6000A/10kA
