| Manufacturer | Siemens |
| Reference | 5SL3032-7KL |
| EAN | 4001869533780 |
| Warranty | 2 years |
| Customs code | 85362010 |
| Product line | Sentron |
| Type of voltage | AC |
| Width in number of modules | 1 |
| Embedding depth | 70 mm |
| Calibre | 32 A |
| Overvoltage category | 3 |
| Energy limitation class (I²t) | 3 |
| Curve | C |
| Degree of pollution | 2 |
| Frequency | 50 Hz |
| Protection class (IP) | IP20 |
| Number of poles | 2 |
| Neutral pole simultaneously disconnected | Yes |
| Auxiliary products that can be combined | Yes |
| Section of connection cable rigid | 0.75 mm² |
| Ambient temperature in operation | -25 °C |
| Tension | 230 V |
| Rated impulse withstand voltage (Uimp) | 4 kV |
| Rated insulation voltage (Ui) | 250 V |
