| Manufacturer | Legrand |
| Reference | 062525 |
| EAN | 3414971404793 |
| Warranty | 2 years |
| Customs code | 94056120 |
| Case color | White |
| Material of the glass | Plastic transparent |
| Material | Plastic |
| Color of light | White |
| Class electric | II |
| Nominal voltage | 207...253 V |
| Type of voltage | AC |
| Height | 125 mm |
| Height/depth | 45 mm |
| Installation height/depth | 55 mm |
| Width | 125 mm |
| Installation width | 160 mm |
| Length | 225 mm |
| Embedding length | 275 mm |
| Depth | 50 mm |
| Embedding depth | 55 mm |
| Power supply of relief | Stand-alone (battery individual) |
| Device | LED driver constant current |
| Autonomy | 1 h |
| Rated current | 2.8...3.5 mA |
| Nominal current of the LED at constant current | 2.8..3.5 mA |
| Rated life L80/B50 at 25°C | 100000 h |
| Light distribution element | Diffuser |
| Power factor (cos phi) | 0.7 |
| Luminous flux (Lumen) | 45 lm |
| Effective luminous flux | 45 lm |
| Protection class (IP) | IP43 |
| Protection class against impacts (IK) | IK07 |
| Number of poles | 4 |
| Number of luminaire heads | 1 |
| Fire protection "D" | No |
| System power | 0.5 W |
| Lighting power | 0.5 W |
| Wire surface | 2.5 mm² |
| Light source included | Yes |
| Type | LED not interchangeable |
| Switch type | Non-permanent |
| Type of installation | Surface and recessed |
| Type of connection | Screw terminal |
| Type of light source | LED |
