| Manufacturer | Ledvance |
| Reference | 552333 |
| EAN | 4058075552333 |
| Warranty | 5 years |
| Customs code | 94054239 |
| Product line | Performance |
| Material of the glass | Glass transparent |
| Material | Aluminum |
| Color of light | White |
| Color rendering index (CRI) | 70 .. 79 |
| Class electric | II |
| Nominal voltage | 220 .. 240 V |
| Type of voltage | AC |
| Height/depth | 90 mm |
| Width | 250 mm |
| Length | 496 mm |
| Device | Ballast electronic |
| Exchangeable control unit | Yes |
| Equipment supplied | Yes |
| IFTTT compatible | Yes |
| Rated current | 277-277 mA |
| Nominal current of the LED at constant current | 277 mA |
| Rated life L70/B50 at 25°C | 100000 h |
| Rated life L80/B10 at 25°C | 100000 h |
| Rated life L90/B10 at 25°C | 100000 h |
| Luminaire efficiency | 142 lm/W |
| Light distribution element | Focus lens |
| Power factor (cos phi) | 0.9 |
| Effective luminous flux | 8250 lm |
| Protection class (IP) | IP66 |
| Protection class against impacts (IK) | IK08 |
| Number of poles | 2 |
| Max. number of luminaires per circuit breaker B16 | 10 |
| Max. number of luminaires per circuit breaker C16 | 21 |
| Fire protection "D" | No |
| System power | 58 W |
| Light source included | Yes |
| Nominal room temperature according to IEC 62722-2-1 | -40-+50 °C |
| Color temperature | 3000 K |
| Type | LED not interchangeable |
| Type of wiring | Termination |
| Type of connection | Automatic bollard |
| Type of connection | File terminal |
| Color uniformity (mcAdam ellipse) | SDCM5 |
| Control via bluetooth | No |
| Possible IFTTT support | Yes |
