| Manufacturer | Ledvance |
| Reference | 109667 |
| EAN | 4058075109667 |
| Customs code | 94051190 |
| Product line | Performance |
| Case color | White |
| Finishing of the louver | Matt |
| Material | Aluminum |
| Beam angle | Faisceau extensif 40-80° |
| Color of light | White |
| Color rendering index (CRI) | 80 .. 89 |
| Class electric | I |
| Nominal voltage | 220 .. 240 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | Yes |
| Suitable for surface mounting | No |
| Suitable for surface mounting | Yes |
| Suitable for flush mounting | No |
| Height/depth | 40 mm |
| Width | 120 mm |
| Length | 1488 mm |
| Suitable for pendant lights | Yes |
| Integrated emergency power supply | No |
| Device | Ballast electronic |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| IFTTT compatible | Yes |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 140-140 mA |
| Nominal current of the LED at constant current | 140 mA |
| Rated life L70/B10 at 25°C | 60000 h |
| Rated life L70/B50 at 25°C | 60000 h |
| Rated life L80/B10 at 25°C | 50000 h |
| Rated life L80/B50 at 25°C | 50000 h |
| Rated life L90/B10 at 25°C | 35000 h |
| Rated life L90/B50 at 25°C | 35000 h |
| Luminaire efficiency | 125 lm/W |
| Light distribution element | Focus lens |
| Light emission | Direct |
| Glare assessment (UGR) | 16 |
| Power factor (cos phi) | 0.9 |
| Effective luminous flux | 3300 lm |
| Photobiological risk group according to EN 62471 | GR1 |
| Protection class (IP) | IP20 |
| Protection class against impacts (IK) | IK06 |
| Wall mounting | No |
| Number of poles | 2 |
| Max. number of luminaires per circuit breaker B16 | 37 |
| Max. number of luminaires per circuit breaker C16 | 48 |
| Fire protection "D" | No |
| System power | 25 W |
| Light distribution | Symmetrical |
| Light source included | Yes |
| Light source included | Yes |
| Harmonic distortion rate | 18 |
| Nominal room temperature according to IEC 62722-2-1 | -20-+45 °C |
| Color temperature | 4000 K |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Type of connection | File terminal |
| Color uniformity (mcAdam ellipse) | SDCM3 |
| Control via bluetooth | No |
| Possible IFTTT support | Yes |
