| Manufacturer | SG Lighting |
| Reference | 630020 |
| EAN | 7021986300208 |
| Warranty | 5 years |
| Customs code | 94051190 |
| Product line | Flom |
| Color | Graphite |
| Case color | Anthracite |
| Material of the glass | Glass matte/satin |
| Material | Aluminum |
| Beam angle | Faisceau très extensif +80° |
| Color of light | White |
| Color rendering index (CRI) | 80 .. 89 |
| Class electric | I |
| Nominal voltage | 240...220 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Suitable for surface mounting | No |
| Suitable for flush mounting | No |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | Yes |
| Suitable for rail mounting | No |
| Suitable for crossbar mounting | No |
| Height | 130 mm |
| Height/depth | 130 mm |
| Width | 52 mm |
| Length | 160 mm |
| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | No required |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy efficiency class of the supplied exchangeable lamp | A++ |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Max. energy efficiency class of the exchangeable lamp | A++ |
| Minimum energy efficiency class of the exchangeable lamp | A++ |
| Start of phase break | No |
| End of phase break | No |
| Rated life L80/B50 at 25°C | 50000 h |
| Luminous efficacy of the lamp | 113 lm/W |
| Luminaire efficiency | 113 lm/W |
| Light emission | Direct |
| Power factor (cos phi) | 0.9 |
| Luminous flux (Lumen) | 2999...2500 lm |
| Effective luminous flux | 2610 lm |
| Protection class (IP) | IP65 |
| Protection class against impacts (IK) | IK06 |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Fire protection "D" | No |
| Accepted lamp power | 23 W |
| System power | 23 W |
| Regulability | Rotatable and steerable |
| Light distribution | Symmetrical |
| Light source included | Yes |
| Light source included | Yes |
| Brushed surface | No |
| Color temperature | 3000 K |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Color uniformity (mcAdam ellipse) | SDCM3 |
