| Device | LED driver constant current |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| Energy class | F |
| Start of phase break | Yes |
| Rated current | 30 mA |
| Integrated diameter | 68 mm |
| Rated life L70/B50 at 25°C | 50000 h |
| Luminaire efficiency | 91.6667 lm/W |
| Light distribution element | Focus lens |
| Light emission | Direct |
| Recessed in insulated ceiling, fire protection "F with roof". | Yes |
| Glare assessment (UGR) | 23 |
| Power factor (cos phi) | 0.9 |
| Luminous flux (Lumen) | 460 lm |
| Effective luminous flux | 550 lm |
| Photobiological risk group according to EN 62471 | GR1 |
| Protection class (IP) | IP65 |
| Protection class against impacts (IK) | IK03 |
| Intensity | 570 cd |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Max. number of luminaires per circuit breaker B16 | 240 |
| Max. number of luminaires per circuit breaker C16 | 306 |
| Fire protection "D" | No |
| System power | 6 W |
| Regulability | Rotary |
| Lumen adjustment | Continuous |
| Light distribution | Symmetrical |
| Wire surface | 0.75 mm² |
| Connectable conductor section | 0.75...2.5 mm² |
| Light source included | Yes |
| Brushed surface | No |
| Harmonic distortion rate | 0.2 |
| Nominal room temperature according to IEC 62722-2-1 | -20.0 .. 40 °C |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Termination |
| Type of connection | Contact for insulation displacement connection |
| Type of connection | Contact for insulation displacement connection |
| Color uniformity (mcAdam ellipse) | SDCM5 |
