| Device | LED driver constant current |
| Exchangeable control unit | Yes |
| Equipment supplied | Yes |
| Energy class | E |
| Rated current | 285...315 mA |
| Integrated diameter | 68...72 mm |
| Rated life L70/B50 at 25°C | 50000 h |
| Light distribution element | Focus lens |
| Light emission | Direct |
| Glare assessment (UGR) | 33 |
| Power factor (cos phi) | 0.9 |
| Luminous flux (Lumen) | 1000 lm |
| Effective luminous flux | 1300 lm |
| Photobiological risk group according to EN 62471 | GR1 |
| Protection class (IP) | IP20 |
| Protection class against impacts (IK) | IK03 |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Max. number of luminaires per circuit breaker B16 | 40 |
| Max. number of luminaires per circuit breaker C16 | 68 |
| Accepted lamp power | 10.6 W |
| System power | 12.3 W |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Wire surface | 0.75 mm² |
| Connectable conductor section | 0.75...2.5 mm² |
| Light source included | Yes |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 3000 K |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | Interchangeable LED |
| Type of wiring | Termination |
| Type of connection | Automatic bollard |
| Color uniformity (mcAdam ellipse) | SDCM5 |
