| Manufacturer | Legrand |
| Reference | 069829L |
| EAN | 3414972110433 |
| Customs code | 85365080 |
| Product line | Plexo |
| Color | Beige |
| Surface finish | Matt |
| Material | Plastic |
| Nominal voltage | 12 V |
| Unit height | 85 mm |
| Device width | 85 mm |
| Device depth | 54 mm |
| Min. depth of the flush-mounted box | 40 mm |
| With lighting | Yes |
| With indicator light indicator | Yes |
| Calibre | 10 A |
| Protection class against impacts (IK) | IK08 |
| Model type | Push button unique |
| Number of actuating rockers | 1 |
| Nombre of contacts en tant que contacts to fermeture number of contacts as make contacts | 1 |
| Nombre of contacts en tant que contacts to ouverture number of contacts as NC contacts | 1 |
| Number of contacts as changeover switches | 1 |
| Number of poles | 1 |
| RAL number | 1013 |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Light source included | Yes |
| Surface treatment | Untreated |
| Type of control | Push button |
| Type of connection | Automatic bollard |
| Type of mounting | Screw mounting |
| Type of installation | Built-in |
| Type of connection | File terminal |
Reference: 069824L
Pushbutton NO-NF light with label holder Plexo - 10A - IP55 - complete- gray
