Porthole sensing rs 16 LED PMMA v2 EU 4000K

008383
4007841008383
Color: White, Product line: Rs pro, Protection class (IP): IP44, Color rendering index (CRI): 80 .. 89, Color temperature: 4000 K
€189.83
€151.86 Save 20%
Tax included Stock: 21 (+ on order) - Delivery within 9 working days in Europe - Price for 1u.
Quantity
In stock (21 u)

100% secure payments
Close
Description

Porthole sensing rs 16 LED PMMA v2 EU 4000K - 008383

Porthole sensing rs 16 LED PMMA v2 EU 4000K
Color temperature
4000K
Beam angle
very extensive beam +80°
Protection class (IP)
IP44
Class electric
class II
Color rendering index (CRI)
80 .. 89

main features - Steinel 008383

  • Color: White
  • Product line: Rs pro
  • Protection class (IP): IP44
  • Color rendering index (CRI): 80 .. 89
  • Color temperature: 4000 K
  • reference: Steinel 008383 / EAN: 4007841008383

High Quality Product

By offering an extended warranty to 3 years, Steinel ensures a high level of quality of this product that will give you satisfaction for many years.
hotline
At your service

You wish to have information on our products or to make a remark or a suggestion on our store? Do not hesitate to contact us .

fast delivery
Optimized logistics!

Delivery times and stocks are indicated on each product sheet and are updated very regularly.

Your satisfaction: our priority

We do everything possible to provide you with quality products and we are listening to you so that you are fully satisfied with your purchases..

Technical specifications

Product information
ManufacturerSteinel
Reference008383
EAN4007841008383
Warranty3 years
Customs code94051140
Product lineRs pro
Design and finish
ColorWhite
Case colorWhite
Material of the glassOpaline plastic
MaterialPlastic
Light information
Beam angleFaisceau très extensif +80°
Color of lightWhite
Color rendering index (CRI)80 .. 89
Electrical information
Class electricII
Nominal voltage220...240 V
Type of voltageAC
Installation / Implementation
Suitable for ceiling mountingYes
Suitable for surface mountingYes
Suitable for surface mountingYes
Suitable for flush mountingNo
Dimensions and weight
Diameter280 mm
Height110 mm
Height/depth88.5 mm
Length110 mm
Technical specifications
Suitable for pendant lightsNo
DeviceLED driver constant current
Equipment suppliedYes
With sensor twilightYes
With sensor of lightYes
With sensor of movementYes
Energy efficiency class of the supplied exchangeable lampA++
Energy efficiency class of the supplied lampA++, A+, A (LED)
Max. energy efficiency class of the exchangeable lampA++
Minimum energy efficiency class of the exchangeable lampA
Start of phase breakNo
End of phase breakNo
Nominal current of the LED at constant current230 mA
Motion sensorYes
Rated life L70/B50 at 25°C50000 h
Luminaire efficiency100.842 lm/W
Light emissionDirect/indirect
Power factor (cos phi)0.92
Effective luminous flux958 lm
Protection class (IP)IP44
Protection class against impacts (IK)IK03
Wall mountingYes
Number of poles2
Fire protection "D"No
Accepted lamp power9.5 W
System power9.5 W
Light distributionSymmetrical
Wire surface6 mm²
Light source includedYes
Light source includedYes
Nominal room temperature according to IEC 62722-2-1-10...40 °C
Color temperature4000 K
Glow-wire test according to IEC 60695-2-11650 °C - 30 s
TypeLED not interchangeable
Type of wiringSuitable for through-wiring
