| Manufacturer | Paulmann |
| Reference | 93430 |
| EAN | 4000870934302 |
| Customs code | 94054239 |
| Product line | Nova |
| Case color | White |
| Beam angle | Faisceau moyen 20-40° |
| Color of light | White |
| Class electric | II |
| Nominal voltage | 230 .. 230 V |
| Suitable for ceiling mounting | No |
| Suitable for surface mounting | No |
| Suitable for flush mounting | No |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | No |
| Suitable for rail mounting | No |
| Diameter | 84 mm |
| Installation height/depth | 90 mm |
| Installation width | 68 mm |
| Embedding length | 68 mm |
| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | No required |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy class | G |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 460 mA |
| Nominal current of the LED at constant current | 460 mA |
| Socket | GU10 |
| Rated life L70/B50 at 25°C | 30000 h |
| Rated life L80/B10 at 25°C | 30000 h |
| Light emission | Direct |
| Luminous flux (Lumen) | 460 lm |
| Effective luminous flux | 460 lm |
| Photobiological risk group according to EN 62471 | GR0 |
| Protection class (IP) | IP23 |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Fire protection "D" | No |
| Accepted lamp power | 6.5 - 6.5 W |
| Regulability | Orientable |
| Light distribution | Symmetrical |
| Connectable conductor section | 1.5 mm² |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 25 °C |
| Color temperature | 2700 K |
| Type of wiring | Through-wiring included |
| Type of connection | Screw terminal |
| Type of connection | Screw terminal |
| Color uniformity (mcAdam ellipse) | SDCM6 |
