| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | LED driver constant current |
| Exchangeable control unit | Yes |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy class | D |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 629 mA |
| Nominal current of the LED at constant current | 762 mA |
| Rated life L80/B10 at 25°C | 75000 h |
| Luminous efficacy of the lamp | 164 lm/W |
| Luminaire efficiency | 124 lm/W |
| Light distribution element | Diffuser |
| Light emission | Direct |
| Power factor (cos phi) | 0.94 |
| Luminous flux (Lumen) | 8000 lm |
| Effective luminous flux | 8000 lm |
| Photobiological risk group according to EN 62471 | GR1 |
| Protection class (IP) | IP66 |
| Protection class against impacts (IK) | IK08 |
| Intensity | 861 cd |
| Wall mounting | Yes |
| Number of lamps/modules | 28 |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 8 |
| Max. number of luminaires per circuit breaker C16 | 13 |
| Fire protection "D" | No |
| Accepted lamp power | 61 W |
| System power | 57 W |
| Regulability | Orientable |
| Lumen adjustment | Continuous |
| Light distribution | Asymmetrical |
| Wire surface | 1.5 mm² |
| Connectable conductor section | 7...14 mm² |
| Light source included | Yes |
| Light source included | Yes |
| Brushed surface | Yes |
| Harmonic distortion rate | 6.52 |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 4000 K |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Termination |
| Type of connection | Contact for insulation displacement connection |
| Type of connection | Contact for insulation displacement connection |
| Color uniformity (mcAdam ellipse) | SDCM3 |
