| Manufacturer | Schneider Electric |
| Reference | S940526 |
| EAN | 3606487213369 |
| Warranty | 2 years |
| Customs code | 85365019 |
| Product line | Odace |
| Color | Black |
| Surface finish | Matt |
| Material | Plastic |
| Nominal voltage | 230...230 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Height | 73.9 mm |
| Width | 73.9 mm |
| Depth | 44 mm |
| Embedding depth | 29 mm |
| Min. depth of the flush-mounted box | 40 mm |
| Angle de détection horizontal | 0 .. 160 ° |
| Running time min. | 1 s |
| Frequency | 50 Hz |
| Optimum mounting height | 1.1 m |
| Protection class (IP) | IP20 |
| Protection class against impacts (IK) | IK04 |
| Max. span width | 8 m |
| Adjustable trigger brightness | Yes |
| Model type | Presence detector |
| Wall mounting | Yes |
| RAL number | 9005 |
| Max. detection range at H 2.5 | 8 m |
| Max. switching capacity | 2200 W |
| Power max. of switching LED | 200 W |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Surface treatment | Untreated |
| Type of sensor | Infrared |
| Type of connection | Screw terminal |
| Type of installation | Built-in |
