| Manufacturer | Schneider Electric |
| Reference | S525052 |
| EAN | 3606481043771 |
| Customs code | 85366990 |
| Product line | Odace |
| Color | White |
| Surface finish | Glossy |
| Material | Plastic |
| Nominal voltage | 250.0 V |
| Nominal voltage | 250 V |
| Unit height | 71.0 mm |
| Unit height | 71 mm |
| Device width | 71.0 mm |
| Device width | 71 mm |
| Device depth | 44.0 mm |
| Device depth | 44 mm |
| Min. depth of the flush-mounted box | 28.0 mm |
| Min. depth of the flush-mounted box | 28 mm |
| Adapted to the protection class (IP) | IP21 |
| With repeater of signal WIFI | No |
| Contact of protection (earth) | Yes |
| Frequency | 50,0 .. 60,0 Hz |
| Protection class against impacts (IK) | IK04 |
| Intensity | 16.0 A |
| Intensity | 16 A |
| Model type | Spindle of contact of protection |
| RAL number | 9003.0 |
| RAL number | 9003 |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Surface treatment | Untreated |
| Type of connection | Automatic bollard |
| Type of mounting | Fastening to claws/Screws |
| Type of installation | Built-in |
| Type of connection | File terminal |
