| Manufacturer | Schneider Electric |
| Reference | NU320620 |
| EAN | 3606489455286 |
| Warranty | 1.5 year |
| Customs code | 85365080 |
| Product line | Unica |
| Color | White |
| Surface finish | Glossy |
| Material | Plastic |
| Nominal voltage | 250.0 V |
| Unit height | 45.0 mm |
| Device width | 45.0 mm |
| Device depth | 30.5 mm |
| Min. depth of the flush-mounted box | 21.15 mm |
| Calibre | 10.0 A |
| Protection class against impacts (IK) | IK04 |
| Model type | Push button unique |
| Number of actuating rockers | 1.0 |
| Nombre of contacts en tant que contacts to fermeture number of contacts as make contacts | 1.0 |
| Nombre of contacts en tant que contacts to ouverture number of contacts as NC contacts | 0.0 |
| Number of contacts as changeover switches | 0.0 |
| Number of modules (modular construction) | 2.0 |
| Number of poles | 1 |
| RAL number | 9003.0 |
| Halogen-free | Yes |
| Type of mounting | Clip-on |
| Type of installation | Built-in |
