| Manufacturer | Theben |
| Reference | 1030052 |
| EAN | 4003468101735 |
| Customs code | 85365080 |
| Product line | Luxa |
| Color | White |
| Surface finish | Matt |
| Material | Plastic |
| Nominal voltage | 230...230 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | Yes |
| Embedding diameter | 60 mm |
| Coupling diameter | 80 mm |
| Height | 62 mm |
| Width | 80 mm |
| Depth | 80 mm |
| Embedding depth | 50 mm |
| Min. depth of the flush-mounted box | 61 mm |
| Angle de détection horizontal | 0 .. 360 ° |
| Self-learning brightness function | Yes |
| Detection field of ground diameter | 12 m |
| Remote controllable | Yes |
| Control auxiliary possible | Yes |
| Current of start max. | 500 A |
| Current of start min. | 0.01 A |
| Running time min. | 15 s |
| Frequency | 50 Hz |
| Optimum mounting height | 3 m |
| Protection class (IP) | IP54 |
| Protection class against impacts (IK) | IK04 |
| Interconnectable | Yes |
| Max. span width | 6 m |
| Adjustable trigger brightness | Yes |
| Model type | Presence detector |
| Wall mounting | No |
| RAL number | 9010 |
| Max. detection range at H 2.5 | 6 m |
| Max. switching capacity | 2300 W |
| Power max. of switching LED | 400 W |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
| Temperature | -25 .. 55 °C |
| Surface treatment | Untreated |
| Type of sensor | Infrared |
| Type of connection | Automatic bollard |
| Type of installation | Built-in |
| Type of connection | File terminal |
