| Manufacturer | SG Lighting |
| Reference | 903215 |
| EAN | 7021989032151 |
| Warranty | 5 years |
| Customs code | 94051190 |
| Product line | Soft |
| Color | White |
| Case color | White |
| Material of the glass | Glass transparent |
| Material | Aluminum |
| Beam angle | Faisceau extensif 40-80° |
| Color of light | White |
| Color rendering index (CRI) | 90 .. 100 |
| Class electric | II |
| Nominal voltage | 230 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Suitable for surface mounting | No |
| Suitable for surface mounting | No |
| Suitable for flush mounting | No |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | No |
| Suitable for rail mounting | No |
| Suitable for crossbar mounting | No |
| Diameter | 94 mm |
| Embedding diameter | 83 mm |
| Height | 51 mm |
| Height/depth | 53 mm |
| Installation height/depth | 53 mm |
| Width | 90 mm |
| Installation width | 83 mm |
| Length | 94 mm |
| Embedding length | 83 mm |
| Suitable for pendant lights | No |
| Bulb(s) included(s) | Yes |
| Device | LED driver constant current |
| With sensor of light | No |
| Energy efficiency class of the supplied exchangeable lamp | A+ |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Max. energy efficiency class of the exchangeable lamp | A+ |
| Minimum energy efficiency class of the exchangeable lamp | A+ |
| Start of phase break | No |
| End of phase break | No |
| Nominal current of the LED at constant current | 0 mA |
| Dimensions | Ø90 x 51 mm ( Ø x H ) |
| Rated life L80/B50 at 25°C | 100000 h |
| Luminous efficacy of the lamp | 89 lm/W |
| Luminaire efficiency | 800 lm/W |
| Light emission | Direct |
| Luminous flux (Lumen) | 800 lm |
| Effective luminous flux | 800 lm |
| Protection class (IP) | IP54 |
| Assembly | Built-in |
| Wall mounting | No |
| Fire protection "D" | No |
| Accepted lamp power | 9 W |
| System power | 9 W |
| Reflector | Ultra glossy |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Wire surface | 2.5 mm² |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 0 °C |
| Color temperature | 3000 K |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Color uniformity (mcAdam ellipse) | SDCM3 |
| Glass | Clear |
