| Device | LED driver constant current |
| Equipment supplied | Yes |
| Energy efficiency class of the supplied exchangeable lamp | A++ |
| Max. energy efficiency class of the exchangeable lamp | A++ |
| Energy class | F |
| Rated life L90/B10 at 25°C | 100000 h |
| Luminous efficacy of the lamp | 57 lm/W |
| Light distribution element | Reflector |
| Light emission | Direct |
| Glare assessment (UGR) | 17.1 |
| Luminous flux (Lumen) | 1000...1499 lm |
| Effective luminous flux | 1020 lm |
| Protection class (IP) | IP20 |
| Wall mounting | No |
| Number of lamps/modules | 3 |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 69 |
| Max. number of luminaires per circuit breaker C16 | 69 |
| Accepted lamp power | 18 .. 18 W |
| System power | 18 W |
| Reflector | Ultra glossy |
| Regulability | Rotatable and steerable |
| Light distribution | Symmetrical |
| Wire surface | 1 mm² |
| Connectable conductor section | 2.5 mm² |
| Light source included | Yes |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 2700 K |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Color uniformity (mcAdam ellipse) | SDCM2 |
| Variation according to the order | Yes |
