| Manufacturer | Ledvance |
| Reference | 799967 |
| EAN | 4058075799967 |
| Customs code | 94054239 |
| Product line | Performance |
| Case color | Black |
| Material of the glass | Plastic transparent |
| Material | Aluminum |
| Beam angle | Faisceau moyen 20-40° |
| Color of light | White |
| Color rendering index (CRI) | 90 .. 100 |
| Class electric | II |
| Nominal voltage | 220 .. 240 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for flush mounting | Yes |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | No |
| Suitable for rail mounting | No |
| Suitable for crossbar mounting | No |
| Diameter | 81 mm |
| Height/depth | 34 mm |
| Installation height/depth | 35 mm |
| Width | 81 mm |
| Installation width | 68 mm |
| Length | 81 mm |
| Embedding length | 68 mm |
| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | LED driver constant current |
| Exchangeable control unit | Yes |
| Equipment supplied | Yes |
| With sensor of light | No |
| IFTTT compatible | Yes |
| Start of phase break | Yes |
| End of phase break | Yes |
| Rated current | 28-28 mA |
| Nominal current of the LED at constant current | 28 mA |
| Integrated diameter | 68-68 mm |
| Rated life L70/B50 at 25°C | 50000 h |
| Luminaire efficiency | 85 lm/W |
| Light distribution element | Focus lens |
| Light emission | Direct |
| Power factor (cos phi) | 0.9 |
| Luminous flux (Lumen) | 510-510 lm |
| Effective luminous flux | 510 lm |
| Photobiological risk group according to EN 62471 | GR1 |
| Protection class (IP) | IP65 |
| Protection class against impacts (IK) | IK03 |
| Wall mounting | No |
| Number of poles | 2 |
| Max. number of luminaires per circuit breaker B16 | 376 |
| Max. number of luminaires per circuit breaker C16 | 457 |
| Fire protection "D" | No |
| System power | 6 W |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Light source included | Yes |
| Light source included | Yes |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | -20-+40 °C |
| Color temperature | 3000 K |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Color uniformity (mcAdam ellipse) | SDCM3 |
| Control via bluetooth | No |
| Possible IFTTT support | Yes |
