Applique LED SU 14W in anodized aluminum with sensor

1020902
4003468101223
Product line: Theleda, Protection class (IP): IP55, Color rendering index (CRI): 80 .. 89, Color temperature: 3000 K
€289.66
€231.72 Save 20%
Tax included Delivery within 23 working days in Europe - Price for 1u.
Quantity
On order / 23 days

100% secure payments
Close
Description

Product characteristics

Wall light LED SU 14W in anodized aluminum with sensor
Color temperature
3000K
Beam angle
Extensive beam 40-80°
Luminous flux (Lumen)
1235lm
Protection class (IP)
IP55
Class electric
class II
Color rendering index (CRI)
80 .. 89

main features

  • Product line: Theleda
  • Protection class (IP): IP55
  • Color rendering index (CRI): 80 .. 89
  • Color temperature: 3000 K
  • reference: Theben 1020902 / EAN: 4003468101223

High Quality Product

Thanks to its aluminium structure this Theleda range luminaire offers you rock-solid strength and guaranteed longevity.
hotline
At your service

You wish to have information on our products or to make a remark or a suggestion on our store? Do not hesitate to contact us .

fast delivery
Optimized logistics!

Delivery times and stocks are indicated on each product sheet and are updated very regularly.

Your satisfaction: our priority

We do everything possible to provide you with quality products and we are listening to you so that you are fully satisfied with your purchases..

Technical specifications

Product information
ManufacturerTheben
Reference1020902
EAN4003468101223
Customs code94054210
Product lineTheleda
Design and finish
Case colorAluminum
Material of the glassPlastic transparent
MaterialAluminum
Light information
Beam angleFaisceau extensif 40-80°
Color of lightWhite
Color rendering index (CRI)80 .. 89
Electrical information
Class electricII
Nominal voltage230 V
Type of voltageAC
Installation / Implementation
Suitable for ceiling mountingNo
Suitable for surface mountingYes
Suitable for surface mountingYes
Suitable for flush mountingNo
Suitable for clamp mountingNo
Suitable for bar mountingNo
Suitable for bearing/floor mountingNo
Suitable for crossbar mountingNo
Dimensions and weight
Height/depth127 mm
Width126 mm
Length65 mm
Technical specifications
Suitable for pendant lightsNo
DeviceNo required
Equipment suppliedYes
With sensor of lightNo
With sensor of movementYes
Energy efficiency class of the supplied lampA++, A+, A (LED)
Start of phase breakNo
End of phase breakNo
Nominal current of the LED at constant current0...10 mA
Degree of protection (NEMA)4
Rated life L80/B50 at 25°C60000 h
Luminous efficacy of the lamp93 lm/W
Luminaire efficiency93 lm/W
Light distribution elementReflector
Light emissionDirect/indirect
Power factor (cos phi)0.95
Luminous flux (Lumen)1235 lm
Effective luminous flux1235 lm
Photobiological risk group according to EN 62471GR0
Protection class (IP)IP55
Protection class against impacts (IK)IK04
Wall mountingYes
Number of poles4
Fire protection "D"No
System power14 W
ReflectorUltra glossy
RegulabilityNot adjustable
Light distributionSymmetrical
Wire surface2.5 mm²
Connectable conductor section0...2.5 mm²
Light source includedYes
Light source includedYes
Brushed surfaceYes
Harmonic distortion rate27
Nominal room temperature according to IEC 62722-2-1-25 .. 45 °C
Color temperature3000 K
Glow-wire test according to IEC 60695-2-11650 °C - 30 s
TypeLED not interchangeable
Type of wiringTermination
Type of connectionScrew terminal
Type of connectionScrew terminal
Color uniformity (mcAdam ellipse)SDCM6
Interface
Variation on manufacturer's proprietary systemYes
