| Manufacturer | Ledvance |
| Reference | 205017 |
| EAN | 4058075205017 |
| Customs code | 94051190 |
| Product line | Value |
| Case color | Grey |
| Material of the glass | Opaline plastic |
| Material | Aluminum |
| Beam angle | Faisceau moyen 20-40° |
| Color of light | White |
| Color rendering index (CRI) | 80 .. 89 |
| Class electric | I |
| Nominal voltage | 220 .. 240 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Suitable for surface mounting | Yes |
| Suitable for flush mounting | No |
| Height/depth | 240 mm |
| Width | 110 mm |
| Length | 176 mm |
| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Device | Ballast electronic |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Energy class | F |
| IFTTT compatible | Yes |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 65-65 mA |
| Rated life L70/B50 at 25°C | 30000 h |
| Luminaire efficiency | 50 lm/W |
| Light distribution element | Diffuser |
| Light emission | Direct |
| Power factor (cos phi) | 0.5 |
| Effective luminous flux | 610 lm |
| Photobiological risk group according to EN 62471 | GR0 |
| Protection class (IP) | IP54 |
| Protection class against impacts (IK) | IK06 |
| Wall mounting | Yes |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 20 |
| Max. number of luminaires per circuit breaker C16 | 28 |
| Fire protection "D" | No |
| System power | 12 W |
| Light source included | Yes |
| Light source included | Yes |
| Nominal room temperature according to IEC 62722-2-1 | -20-+40 °C |
| Color temperature | 3000 K |
| Type | LED not interchangeable |
| Type of wiring | Termination |
| Type of connection | Screw terminal |
| Type of connection | Screw terminal |
| Color uniformity (mcAdam ellipse) | SDCM6 |
| Control via bluetooth | No |
| Possible IFTTT support | Yes |
