| Manufacturer | Bailey |
| Reference | 146041 |
| EAN | 8714681460412 |
| Customs code | 94051140 |
| Case color | Grey |
| Material | Plastic |
| Beam angle | Faisceau très extensif +80° |
| Color of light | White |
| Color rendering index (CRI) | 80 .. 89 |
| Class electric | II |
| Nominal voltage | 220...240 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for flush mounting | No |
| Height/depth | 95 mm |
| Width | 65 mm |
| Length | 165 mm |
| Device | LED driver constant current |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| Degree of protection (NEMA) | 3 |
| Rated life L70/B50 at 25°C | 35000 h |
| Light emission | Direct |
| Glare assessment (UGR) | 30 |
| Power factor (cos phi) | 0.5 |
| Effective luminous flux | 750 lm |
| Protection class (IP) | IP54 |
| Protection class against impacts (IK) | IK08 |
| Intensity | 205 cd |
| Wall mounting | Yes |
| Number of lamps/modules | 1 |
| Number of poles | 3 |
| Accepted lamp power | 4.5 .. 7.5 W |
| System power | 7.5 W |
| Lumen adjustment | Levels |
| Light distribution | Symmetrical |
| Wire surface | 2.5 mm² |
| Light source included | Yes |
| Nominal room temperature according to IEC 62722-2-1 | -30 °C |
| Color temperature | 4000 K |
| Glow-wire test according to IEC 60695-2-11 | 650 °C - 30 s |
| Type | Interchangeable LED |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Color uniformity (mcAdam ellipse) | SDCM6 |
| Control via bluetooth | No |
