| Manufacturer | Bailey |
| Reference | 146004 |
| EAN | 8719322372901 |
| Customs code | 94051190 |
| Case color | White |
| Material of the glass | Glass transparent |
| Material | Aluminum |
| Beam angle | Faisceau très extensif +80° |
| Color of light | White |
| Color rendering index (CRI) | 90 .. 100 |
| Class electric | II |
| Nominal voltage | 12.5 V |
| Type of voltage | DC |
| Suitable for ceiling mounting | Yes |
| Suitable for flush mounting | Yes |
| Diameter | 62 mm |
| Height/depth | 14 mm |
| Installation height/depth | 14 mm |
| Installation width | 55 mm |
| Embedding length | 62 mm |
| Device | Electronic transformer |
| Exchangeable control unit | Yes |
| Energy class | G |
| Rated current | 260 mA |
| Rated life L70/B50 at 25°C | 50000 h |
| Light distribution element | Reflector |
| Light emission | Direct |
| Power factor (cos phi) | 0.9 |
| Effective luminous flux | 240 lm |
| Photobiological risk group according to EN 62471 | GR0 |
| Protection class (IP) | IP54 |
| Intensity | 130 cd |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Accepted lamp power | 3 W |
| Lumen adjustment | Continuous |
| Light distribution | Symmetrical |
| Wire surface | 0.5 mm² |
| Light source included | Yes |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 2700 K |
| Type | LED not interchangeable |
| Type of wiring | Termination |
| Color uniformity (mcAdam ellipse) | SDCM6 |
| Control via bluetooth | No |
