TeSys GB2-CB - circuit breaker for control circuit - 6A - 1P - 1D

GB2CB12
3389110214697
Product line: Tesys gb2, Protection class (IP): IP20
€41.44
€33.15 Save 20%
Tax included Stock: 4 (+ on order) - Delivery within 10 working days in Europe - Price for 1u.
Quantity
In stock (4 u)

100% secure payments
Close
Description

TeSys GB2-CB - circuit breaker for control circuit - 6A - 1P - 1D - GB2CB12

TeSys GB2-CB - circuit breaker for control circuit - 6A - 1P - 1D
Protection class (IP)
IP20

main features - Schneider Electric GB2CB12

  • Product line: Tesys gb2
  • Protection class (IP): IP20
  • reference: Schneider Electric GB2CB12 / EAN: 3389110214697
Schneider Electric
Schneider Electric

Find all the products of the brand Schneider Electric at the best price on the store domeashop.com.

See all products Schneider Electric
hotline
At your service

You wish to have information on our products or to make a remark or a suggestion on our store? Do not hesitate to contact us .

fast delivery
Optimized logistics!

Delivery times and stocks are indicated on each product sheet and are updated very regularly.

Your satisfaction: our priority

We do everything possible to provide you with quality products and we are listening to you so that you are fully satisfied with your purchases..

Technical specifications

Product information
ManufacturerSchneider Electric
ReferenceGB2CB12
EAN3389110214697
Customs code85362010
Product lineTesys gb2
Electrical information
Type of voltageAC
Installation / Implementation
Suitable for flush mountingNo
Dimensions and weight
Width in number of modules1.0
Width in number of modules1
Embedding depth74.0 mm
Embedding depth74 mm
Technical specifications
Calibre6.0 A
Calibre6 A
Overvoltage category3
Energy limitation class (I²t)3
Degree of pollution2
Frequency50,0 .. 60,0 Hz
Frequency60,0 .. 50,0 Hz
Protection class (IP)IP20
Number of poles1.0
Number of poles1
Number of poles protected1.0
Number of poles protected1
Neutral pole simultaneously disconnectedNo
Section of connection cable rigid0,75 .. 6,0 mm²
Section of connection cable rigid6,0 .. 0,75 mm²
Ambient temperature in operation-20,0 .. 60,0 °C
Ambient temperature in operation-20,0 60,0 °C
Tension250.0 V
Tension250 V
Rated impulse withstand voltage (Uimp)4.0 kV
Rated impulse withstand voltage (Uimp)4 kV
Rated insulation voltage (Ui)250.0 V
Rated insulation voltage (Ui)250 V

Documentation

Brochures and data sheets

Consult the manufacturer's technical documentation and instructions to guide you in the safe use of your product in accordance with the regulations.
documentationProduct sheet - Schneider Electric GB2CB12
