| Manufacturer | SG Lighting |
| Reference | 905250 |
| EAN | 7021989052500 |
| Customs code | 94051190 |
| Product line | Junistar |
| Case color | White |
| Material of the glass | Glass transparent |
| Material | Plastic |
| Suitable for ceiling mounting | Yes |
| Suitable for surface mounting | No |
| Suitable for flush mounting | Yes |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | No |
| Suitable for crossbar mounting | No |
| Suitable for pendant lights | No |
| Integrated emergency power supply | No |
| Beam angle | Extensive beam 40-80° |
| Device | LED driver constant current |
| Equipment supplied | Yes |
| With sensor of light | No |
| Class electric | II |
| Color of light | White |
| Start of phase break | No |
| End of phase break | Yes |
| Nominal current of the LED at constant current | -..- mA |
| Integrated diameter | 83 mm |
| Luminaire efficiency | 100 lm/W |
| Light distribution element | Focus lens |
| Light emission | Direct |
| Glare assessment (UGR) | 18.7 |
| Luminous flux (Lumen) | 999...500 lm |
| Effective luminous flux | 500 lm |
| Installation height/depth | 56 mm |
| Protection class (IP) | IP44 |
| Color rendering index (CRI) | 90 .. 100 |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 112 |
| Max. number of luminaires per circuit breaker C16 | 190 |
| Fire protection "D" | No |
| Accepted lamp power | 5 W |
| System power | 5 W |
| Reflector | Ultra glossy |
| Regulability | Orientable |
| Light distribution | Symmetrical |
| Wire surface | 1 mm² |
| Connectable conductor section | 2.5...0.5 mm² |
| Light source included | Yes |
| Nominal room temperature according to IEC 62722-2-1 | 25 °C |
| Color temperature | 2700 K |
| Nominal voltage | 240...220 V |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of voltage | AC |
| Color uniformity (mcAdam ellipse) | SDCM2 |
| Diameter | 94mm |
| Height/depth | 59 mm |
| Width | 94 mm |
| Installation width | 83 mm |
| Length | 94 mm |
| Embedding length | 83 mm |
