Protection class (IP): IP54
You wish to have information on our products or to make a remark or a suggestion on our store? Do not hesitate to contact us .
Delivery times and stocks are indicated on each product sheet and are updated very regularly.
We do everything possible to provide you with quality products and we are listening to you so that you are fully satisfied with your purchases..
| Manufacturer | SG Lighting |
| Reference | 903214 |
| EAN | 7021989032144 |
| Customs code | 94051190 |
| Product line | Soft |
| Case color | White |
| Material of the glass | Glass transparent |
| Material | Aluminum |
| Beam angle | Faisceau extensif 40-80° |
| Color of light | White |
| Color rendering index (CRI) | 90 .. 100 |
| Class electric | II |
| Nominal voltage | 230 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Suitable for surface mounting | No |
| Suitable for surface mounting | No |
| Suitable for flush mounting | No |
| Suitable for clamp mounting | No |
| Suitable for bar mounting | No |
| Suitable for bearing/floor mounting | No |
| Suitable for rail mounting | No |
| Suitable for crossbar mounting | No |
| Diameter | 94 mm |
| Embedding diameter | 83 mm |
| Height/depth | 53 mm |
| Installation height/depth | 53 mm |
| Width | 94 mm |
| Installation width | 83 mm |
| Length | 94 mm |
| Embedding length | 83 mm |
| Suitable for pendant lights | No |
| Device | LED driver constant current |
| With sensor of light | No |
| Energy efficiency class of the supplied exchangeable lamp | A+ |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Max. energy efficiency class of the exchangeable lamp | A+ |
| Minimum energy efficiency class of the exchangeable lamp | A+ |
| Start of phase break | No |
| End of phase break | No |
| Nominal current of the LED at constant current | 0 mA |
| Rated life L80/B50 at 25°C | 100000 h |
| Luminous efficacy of the lamp | 83 lm/W |
| Luminaire efficiency | 750 lm/W |
| Light emission | Direct |
| Luminous flux (Lumen) | 750 lm |
| Effective luminous flux | 750 lm |
| Protection class (IP) | IP54 |
| Wall mounting | No |
| Fire protection "D" | No |
| Accepted lamp power | 9 W |
| System power | 9 W |
| Reflector | Ultra glossy |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Wire surface | 2.5 mm² |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 0 °C |
| Color temperature | 2700 K |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Color uniformity (mcAdam ellipse) | SDCM3 |
Reference: 940440
Jupiter Pro 2200 downlight white 40° 2370lm 4000K Ra sup 90 phase break
