| Manufacturer | SG Lighting |
| Reference | 940353 |
| EAN | 7021989403531 |
| Customs code | 94051190 |
| Product line | Jupiter pro |
| Case color | Multicolor |
| Material of the glass | Glass transparent |
| Material | Aluminum |
| Beam angle | Faisceau moyen 20-40° |
| Color of light | White |
| Color rendering index (CRI) | 90 .. 100 |
| Class electric | II |
| Nominal voltage | 220...240 V |
| Type of voltage | AC |
| Suitable for ceiling mounting | No |
| Suitable for flush mounting | Yes |
| Suitable for clamp mounting | Yes |
| Diameter | 114 mm |
| Embedding diameter | 83 mm |
| Height/depth | 111 mm |
| Installation height/depth | 110 mm |
| Device | LED driver constant current |
| Exchangeable control unit | No |
| Energy efficiency class of the supplied exchangeable lamp | A++ |
| Max. energy efficiency class of the exchangeable lamp | A++ |
| Minimum energy efficiency class of the exchangeable lamp | A++ |
| Rated life L90/B10 at 25°C | 100000 h |
| Luminous efficacy of the lamp | 84 lm/W |
| Light distribution element | Reflector |
| Light emission | Direct |
| Luminous flux (Lumen) | 1850 lm |
| Protection class (IP) | IP44 |
| Intensity | 1850 cd |
| Wall mounting | No |
| Number of lamps/modules | 1 |
| Number of poles | 2 |
| Accepted lamp power | 22 .. 22 W |
| System power | 22 W |
| Reflector | Ultra glossy |
| Regulability | Not adjustable |
| Light distribution | Symmetrical |
| Wire surface | 1 mm² |
| Connectable conductor section | 2.5 mm² |
| Light source included | Yes |
| Brushed surface | No |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 4000 K |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Color uniformity (mcAdam ellipse) | SDCM2 |
| Variation according to the order | Yes |
| Control via bluetooth | No |
| DALI variation | Yes |
