| Suitable for pendant lights | Yes |
| Integrated emergency power supply | No |
| Bulb(s) included(s) | Yes |
| Device | LED driver constant current |
| Exchangeable control unit | No |
| Equipment supplied | Yes |
| With sensor of light | No |
| Energy efficiency class of the supplied lamp | A++, A+, A (LED) |
| Max. energy efficiency class of the exchangeable lamp | A |
| Minimum energy efficiency class of the exchangeable lamp | A++ |
| Energy class | A+ |
| Start of phase break | No |
| End of phase break | No |
| Rated current | 140 mA |
| Nominal current of the LED at constant current | 295-295 mA |
| Dimensions | 1200 x 87 x 96 mm ( L x L x H ) |
| Life span | 50000 h |
| Rated life L70/B50 at 25°C | 75000 h |
| Rated life L80/B50 at 25°C | 50000 h |
| Rated life L90/B50 at 25°C | 15000 h |
| Luminaire efficiency | 140 lm/W |
| Light distribution element | Diffuser |
| Light emission | Direct |
| Recessed in insulated ceiling, fire protection "F with roof". | Yes |
| Glare assessment (UGR) | 25 |
| Power factor (cos phi) | 0.9 |
| Luminous flux (Lumen) | 4000 lm |
| Effective luminous flux | 4000 lm |
| Photobiological risk group according to EN 62471 | GR0 |
| Protection class (IP) | IP65 |
| Protection class against impacts (IK) | IK08 |
| Wall mounting | Yes |
| Number of lamps/modules | 1 |
| Number of poles | 3 |
| Max. number of luminaires per circuit breaker B16 | 36 |
| Max. number of luminaires per circuit breaker C16 | 60 |
| Fire protection "D" | Yes |
| Accepted lamp power | - W W |
| System power | 28.6 W |
| Reflector | White |
| Light distribution | Symmetrical |
| Wire surface | 0.5 mm² |
| Light source included | Yes |
| Light source included | Yes |
| Harmonic distortion rate | 20 |
| Ambient temperature | 20-35 °C |
| Nominal room temperature according to IEC 62722-2-1 | 25 .. 25 °C |
| Color temperature | 4000 K |
| Glow-wire protection | 850 °C - 5s |
| Glow-wire test according to IEC 60695-2-11 | 850 °C - 30 s |
| Type | LED not interchangeable |
| Type of wiring | Suitable for through-wiring |
| Type of connection | Automatic bollard |
| Type of connection | File terminal |
| Color uniformity (mcAdam ellipse) | SDCM3 |
